Biped question


Post new topic   Reply to topic    IMVU Forum Index -> 3D Developing
View previous topic :: View next topic
Author Message
Pharmacist

Pharmacist's page


Joined: 20 Oct 2007
Posts: 742
Location: USA

PostPosted: Tue May 04, 2010 4:08 pm    Post subject: Biped question Reply with quote

Hello,
I have a question about how to merge a biped into the female weighting file.

Say I have a cat which is rigged and ready for animation. When I try to merge it into the avatar female file, it never merged the right way. Any idea how to merge it correctly?

Thanks in advance.
Back to top
View user's profile Send private message
Blackjack

Blackjack's page


Joined: 01 Nov 2009
Posts: 29
Location: USA - NV

PostPosted: Wed May 05, 2010 8:16 am    Post subject: Reply with quote

I just did a test with Max 2008, merging in one of the sample files that came with Max (cs4_tut_quad_WallyFinal.max). That file is a "quadruped" creature/mesh using a Biped System. It did merge it in upside down and very small, but I'm guessing that's because the two had been saved with different units. Otherwise, it seemed to merge fine. Both the quadruped and the avatar retained their animation and weighting and deformed correctly as I move the time slider.
Back to top
View user's profile Send private message
Pharmacist

Pharmacist's page


Joined: 20 Oct 2007
Posts: 742
Location: USA

PostPosted: Wed May 05, 2010 8:53 am    Post subject: Reply with quote

Everything is turned upside down and very small is what I get each time I am trying to merge it. So how can I fix the units system of my biped characters to be the same as the female file?

When I try to rotate it to be what I want, it looks okay but once I open the physique, it returns to the upside down status.
Back to top
View user's profile Send private message
Blackjack

Blackjack's page


Joined: 01 Nov 2009
Posts: 29
Location: USA - NV

PostPosted: Wed May 05, 2010 11:35 am    Post subject: Reply with quote

If you open your max file with the Biped and change the units and resave, that should fix it on import. In Max 2008 (might be elsewhere on other versions):
Customize (menu)
->Units Setup... (menu)
->System Unit Setup (button)

On the System Unit Setup menu you can change the scale from "1 Unit =" to "1 Meters" to match the Avatar. Click ok through the dialogs and save and you should be good to go.

The changing of the units fixed the rotation for me, but not the scale - very odd, as I'd have expected the opposite. Scaling a mesh that's skinned/physiqued to Biped might need something special. If your non-avatar mesh has Physique, the following might help:
http://forums.cgsociety.org/archive/index.php/t-558.html
Back to top
View user's profile Send private message
EternaSky 18+ Age Verified

EternaSky <a href='/age_verify/index/'><img src='/common/img/icons/age_verified_35x18.gif' width='35' height='18' alt='18+ Age Verified'/></a> 's page


Joined: 03 Dec 2006
Posts: 4600
Location: Singapore

PostPosted: Thu May 06, 2010 12:57 am    Post subject: Re: Biped question Reply with quote

Pharmacist wrote:
Hello,
I have a question about how to merge a biped into the female weighting file.

Say I have a cat which is rigged and ready for animation. When I try to merge it into the avatar female file, it never merged the right way. Any idea how to merge it correctly?

Thanks in advance.


rigged with biped?

Here's a slower way but surefire method
First save your physique .phys
next save your .fig and .bip file of the biped
then remvoe the physique
then merge the model in else u can export as .3ds and reimport

after merging, create a biped of any make u like.
load in the .fig
adjust accordingly due to scale issues

load in the .phys
then load in the .bip

Slow, but surefire way with less hassle of scale and export issues to tinker with later.
_________________
Back to top
View user's profile Send private message
Pharmacist

Pharmacist's page


Joined: 20 Oct 2007
Posts: 742
Location: USA

PostPosted: Fri May 07, 2010 4:37 pm    Post subject: Reply with quote

Thank you Blackjack and EternaSky. I will try to make both of your steps. I know a little about the .Phy and the .bip file formats. But what is the .fig one? How can I save my file as .Fig?

Sorry. This is my first rigged character ever. So I know I need to read more about this.

Thanks.
Back to top
View user's profile Send private message
EternaSky 18+ Age Verified

EternaSky <a href='/age_verify/index/'><img src='/common/img/icons/age_verified_35x18.gif' width='35' height='18' alt='18+ Age Verified'/></a> 's page


Joined: 03 Dec 2006
Posts: 4600
Location: Singapore

PostPosted: Mon May 10, 2010 12:28 am    Post subject: Reply with quote

.fig is the figure file. u save it by accessing the biped's figure mode.
the figure mode is what u use to change the length. number of bones etc.
_________________
Back to top
View user's profile Send private message
Pharmacist

Pharmacist's page


Joined: 20 Oct 2007
Posts: 742
Location: USA

PostPosted: Mon May 17, 2010 8:01 pm    Post subject: Reply with quote

@Blackjack, system unit is important for me all the time. Thank you for this tip.

@EternaSky, Thank you so much. this method is really surefire. I tried it and it worked for me.
Back to top
View user's profile Send private message
EternaSky 18+ Age Verified

EternaSky <a href='/age_verify/index/'><img src='/common/img/icons/age_verified_35x18.gif' width='35' height='18' alt='18+ Age Verified'/></a> 's page


Joined: 03 Dec 2006
Posts: 4600
Location: Singapore

PostPosted: Wed May 19, 2010 3:14 am    Post subject: Reply with quote

glad to see it solved Smile
_________________
Back to top
View user's profile Send private message
Gusthy43 18+ Age Verified

Gusthy43 <a href='/age_verify/index/'><img src='/common/img/icons/age_verified_35x18.gif' width='35' height='18' alt='18+ Age Verified'/></a> 's page


Joined: 15 Feb 2009
Posts: 36
Location: Hungary

PostPosted: Wed May 26, 2010 10:38 am    Post subject: Re: Biped question Reply with quote

EternaSky wrote:

...
next save your .fig and .bip file of the biped
...


i have a lil problem with this step
a simple steps:
open the original bipedRig_Basic.max file
select biped
press fig button to switch figure mode


and voila somethin happened the avatar shoulders, move a litle to down

here the screencapture:
http://gusthy.webege.com/err/err.html
Back to top
View user's profile Send private message
EternaSky 18+ Age Verified

EternaSky <a href='/age_verify/index/'><img src='/common/img/icons/age_verified_35x18.gif' width='35' height='18' alt='18+ Age Verified'/></a> 's page


Joined: 03 Dec 2006
Posts: 4600
Location: Singapore

PostPosted: Wed May 26, 2010 11:37 pm    Post subject: Reply with quote

dun worry about it, leaving figure mode should fix it
also i tend to not use the 4 viewport mode to see anything major. I love expanded view.

the .fig is simply how the Biped is structured.

This is also why u save the .bip file and in fact save the .bip file first.

In figure mode u decide how many neck bones, spine bones, ankle blah blah.
IMVU uses the default structure so not a big problem if u don't save figure mode.

However to prevent any possibility of a compromise. it's generally recommended to save the .fig

But this is only for an extreme backup case. which the topic here relates to.
